Gallery

Every drawing on this site in one place, fitted together edge to edge.

Arrow keys move between figures, Space or Enter opens one large, Option with Left or Right Arrow moves it, plus and minus zoom. A double-click opens a figure like Space.

Process flowsheet: feed, reactor, flash separator and recycle loopOrthographic process flow diagram drawn as sectioned equipment. Fresh feed (stream 1) meets the recycle in a static mixer, passes down through a fixed-bed catalytic reactor, is cooled in a single-pass shell-and-tube cooler against counter-current cooling water (supply in at the bottom, return out at the top), and is split in a flash drum. Liquid leaves as product (stream 6); vapour rises to a tee where a small purge (stream 7) leaves through a control valve and the rest is recompressed and recycled (stream 8) to the mixer.12345678CWRCWSLCRECYCLEFEEDREACTORPURGEFLASHPRODUCTCOOLER
Process flowsheet: feed, catalytic reactor, cooler and flash separator, with recycle compressor and purge.
Packed-bed reactor with axial conversion and temperature profiles Isometric fixed-bed catalytic reactor with a quarter cut-away through shell, coolant jacket and bed: spherical catalyst pellets between perforated support grids, feed in at the left nozzle, product out at the right, coolant counter-current in the jacket. Below, on the reactor's own axis z, a 1-D plug-flow model (first-order exothermic reaction, Arrhenius rate, cooled wall; Da 1.4, St 6, ΔTad 170 K, γ 20, T0 = Tc = 600 K): conversion X(z) rises to 0.984; temperature T(z) peaks at a 670 K hot spot at z/L = 0.28, then the jacket cools it back. 700 K600 K100LzHOT SPOTTEMPERATURE T(z)CONVERSION X(z)FEEDPLUG-FLOW MODELDa1.4St6ΔTad170 Kγ20T0 = Tc600 KPRODUCTCATALYST BEDSUPPORT GRIDCOOLANTCOOLANT
Fixed-bed catalytic reactor, cut away, with the axial conversion and temperature profiles of a 1-D plug-flow model below it.
PEM electrolyzer stack, assembled and exploded isometric view A proton-exchange-membrane electrolyzer cell, shown clamped (plates flush on the membrane, tie rods inside the stack, nuts tight on the top end plate) and pulled apart along four tie rods at one even spacing, with dashed axes running port to port through three manifolds: the bottom end plate with the water inlet feeding the water manifold, a bipolar plate whose pixel serpentine flow field runs from the water port to the oxygen-and-water port through short feed channels, while the hydrogen port is sealed off by its own O-ring, the membrane electrode assembly, a second bipolar plate, and the top end plate carrying the oxygen outlet on the anode manifold and the hydrogen outlet on the cathode manifold, where bubbles rise at a two-to-one hydrogen-to-oxygen ratio. O₂ OUTH₂ OUTTIE RODMEMBRANE (MEA)END PLATEH₂O INBIPOLAR PLATE░▒▓ 2H₂O → 2H₂ + O₂
PEM electrolyzer stack, exploded: end plates, bipolar plates, membrane electrode assembly, H₂ and O₂ outlets.
One causal self-attention head Seven tokens t₁ to t₇ each look up a 6-dimensional embedding, drawn as a strip of pixels. Three learned projections W_Q, W_K and W_V map every embedding to a 4-dimensional query, key and value. The queries sit beside the attention matrix and the keys stand above it as columns, so cell (i, j) holds softmax over keys of q_i·k_j/√d with d = 4. A causal mask removes every key that comes after its query, so the hatched upper triangle is zero and each row sums to one. One query row is highlighted; its weights a_i, turned on their side next to the values, set the strength of the lines that sum the values into the output vector z_i. The highlight sweeps down the rows one query at a time. t₁t₂t₃t₄t₅t₆t₇TOKENS EMBEDDINGS WKQKTVWQWV CAUSAL MASKSOFTMAX(QKT/√d) ai OUTPUT z01
One causal self-attention head: queries, keys and values, the softmax(QKᵀ/√d) weights with the causal mask, and one output as a weighted sum.
k-nearest-neighbour classification A two-feature plane, x₁ and x₂ from 0 to 10 on equal scales, with 42 labelled training samples in three classes (A filled, B open, C ringed dot; A: 14 draws from a normal distribution centred at (2.9, 6.6), sd 1.15; B: 14 draws from a normal distribution centred at (6.8, 6.9), sd 1.15; C: 14 draws from a normal distribution centred at (5, 2.9), sd 1.2; seed 20261007). The query point (7.5, 4.4) is joined to its k = 5 nearest samples by Euclidean distance; the circle has radius d₅ = 1.85, the distance to the 5th neighbour. Majority vote A 0, B 3, C 2: predicted class B (k = 1 would predict C). Dither fills the region each class wins under 5-NN (B is left blank); its edge and the ink line are the decision boundary, traced to within 1 plotted unit. Distance ties go to the lower sample index, vote ties to the tied class with the nearest member. 00224466881010x₂x₁ NEIGHBOURHOOD DECISION BOUNDARY QUERYCLASS ACLASS BCLASS C QUERY(7.50, 4.40)VOTEk = 5 CLASS A0CLASS B3CLASS C2 PREDICTIONCLASS B NEARESTd 10.4721.3131.6341.8351.85 r = d₅1.85
k-nearest-neighbour classification: three classes, the decision regions for k = 5, and one query’s vote.
Gradient descent on a loss landscape Exploded isometric view. A quadratic loss surface L(θ), drawn as a mesh with banded level sets, floats above the parameter space θ, where the same level sets appear rasterised into pixel-stepped dither bands. Starting at θ₀, gradient descent takes the exact updates θₖ₊₁ = θₖ − η∇L(θₖ): each step runs opposite the gradient ∇L(θ₀), drawn perpendicular to the level set through θ₀, zig-zagging across the steep valley walls and converging into the minimum. ΔL(θ₀)θ₀ηLOSSSURFACEMINIMUMPARAMETERSPACE θHILO
Gradient descent on a quadratic loss surface: iterates θₖ₊₁ = θₖ − η∇L(θₖ) converging to the minimum.
Split-conformal prediction interval on a 24-hour demand forecast The last 36 hours of hourly electricity demand in GW (synthetic, seeded daily cycle with noise) end at a vertical NOW line. A seasonal-profile model, the mean of the same hour over the previous 7 days, forecasts the next 24 hours as a heavy line. Around it, a split-conformal 90% interval is drawn as grid-snapped pixel cells, one column per forecast hour, under its exact vector edges: the band is the forecast plus or minus q-hat. To the right, a pixel histogram of 336 calibration residuals |y − ŷ| shares the same vertical scale; q-hat = 1.60 GW, the 304th smallest of the 336 residuals (k = ceil((n+1)(1−α)), α = 0.1), is a horizontal line that meets the band's upper edge, and a dimension bracket shows that the band half-width equals q-hat. The actual next-day demand is a faint dashed line; 22 of 24 hours fall inside the band, shown by a coverage strip under the time axis. GW303540−36 H−24 H−12 HCOVERAGE22/24 = 92%HISTORYNOWACTUALFORECAST ŷ90% INTERVAL|y−ŷ|qqq = 1.60 GWCALIBRATIONRESIDUALS
Day-ahead forecast with a split-conformal interval: the band half-width is the calibrated quantile q̂ of past residuals.
Exploded sieve-tray distillation column Isometric exploded view of a distillation column. The shell is cut open to show the sump liquid; three sieve trays with perforated decks, outlet weirs and downcomers are lifted out above it; the top head carries the vapour line to an overhead condenser and reflux drum, and a thermosyphon reboiler returns vapour to the base. Vapour rises through the trays while liquid falls down the downcomers. Closed, the trays sit inside a full flanged shell under the head. SIEVE TRAYDOWNCOMERFEEDCONDENSERREFLUX DRUMDISTILLATEREBOILERBOTTOMS
Sieve-tray distillation column, exploded: feed, trays and downcomers, reboiler below, condenser and reflux drum above.
Direct distillation sequence: A | BCD, B | CD, C | DOrthographic process flow diagram of a direct distillation sequence for a four-component mixture A, B, C, D (A lightest). Feed ABCD enters C-101, which takes A overhead and leaves BCD; C-102 takes B overhead and leaves CD; C-103 splits C from D. Each sieve-tray column is drawn in section with its total condenser (two-pass, cooling water on the tubes), reflux drum, inline reflux pump and kettle reboiler (steam in the U-bundle). Columns stand on a common base and narrow down the sequence as the feed shrinks (diameter ∝ √feed: 1, 0.75, 0.5); tray counts follow assumed relative volatilities α_AB 2.0, α_BC 3.0, α_CD 3.6 (Fenske, 99 % key recovery), feed trays follow Kirkbride: C-101 11 trays, feed above tray 6; C-102 7 trays, feed above tray 4; C-103 6 trays, feed above tray 4. Pressure falls from C-101 to C-103, so each bottoms product flows to the next column's feed tray by pressure difference, without a pump. C-101 CWRCWSE-101 V-101 P-101 STMCNDE-102 ABCDABCD C-102 CWRCWSE-103 V-102 P-102 STMCNDE-104 BCD C-103 CWRCWSE-105 V-103 P-103 STMCNDE-106 CD
Direct distillation sequence for a four-component feed: A | BCD, then B | CD, then C | D.
McCabe–Thiele stage construction McCabe–Thiele diagram for a binary distillation with constant relative volatility α = 2.5. The hero curve is the equilibrium line y = αx / (1 + (α − 1)x); the thin diagonal is y = x. Feed: z_F = 0.5, q = 0.6 (60 % liquid), so the q-line through (z_F, z_F) has slope q/(q − 1) = −1.50 and meets the equilibrium curve at the pinch (0.410, 0.635), which gives R_min = 1.180. At R = 1.4 R_min = 1.653 the rectifying operating line runs from (x_D, x_D) = (0.9, 0.9) with slope R/(R + 1) = 0.623 to its intersection with the q-line at (0.429, 0.607); the stripping line runs from there to (x_B, x_B) = (0.1, 0.1). Stepping from the top, alternately horizontal to the equilibrium curve and vertical to the active operating line, switching at the feed stage, gives 9 theoretical stages (8.97 by fractional count, reboiler included), with stage 5 as the optimal feed stage. The stair region is rasterised onto the grid underneath the exact vector staircase. 1 2 3 4 5 6 7 8 9 ROP q-LINE SOP EQUILIBRIUM THEORETICAL STAGE FEED STAGE y (VAPOUR) x (LIQUID) 1 0 1 xB 0.10 zF 0.50 xD 0.90 α = 2.5 q = 0.6 R = 1.4 Rmin = 1.65 N = 9, FEED = 5
McCabe–Thiele construction for a binary column: equilibrium curve, q-line, rectifying and stripping lines, and the theoretical stages stepped off at R = 1.4·R_min.
Shell-and-tube heat exchanger — two-pass U-tube section Four hollow U-tubes return the cold stream from the lower channel chamber to the upper outlet. A sealed divider separates the two channel chambers. The hot shell-side stream enters at the upper left, passes through alternating segmental-baffle windows, and leaves at the lower right. Hatched walls and tube sheet show sectioned metal; arrowheads distinguish the two fluid circuits without mixing them. The assembled view shows the same unit from outside: shell, bolted girth flange with the tube-sheet rim, channel bonnet, nozzles and saddles. Probe layer (hidden at rest): pointing along the section places a thermocouple traverse at that station and reads the shell and both tube-pass temperatures from the 1-2 exchanger model - shell fluid mixed over each cross-section, plug flow in each pass, constant U, U-bend area not counted - for hot in 150 °C, cold in 30 °C, Cc/Ch = 0.8, UA/Cc = 1.5: hot out 95.5 °C, cold out 98.2 °C, F = 0.78. Arrows give the local heat-flow direction; past x/L = 0.93 the upper pass is hotter than the shell and returns heat to it. Below the section, a temperature profile from the same model: shell T and both tube passes against x/L (axis aligned with the straight tube length), the cross marked; while probing, a cursor follows the station. HOT IN SHELL COLD OUT TUBE SHEET TUBE BUNDLE BAFFLE 306090120150°C00.250.50.751x/LSHELLPASS 2PASS 1CROSS
U-tube shell-and-tube heat exchanger, sectioned: shell-side flow across the baffles, counter-current tube-side flow.
Neural network: raster input to softmax output An 8 by 8 pixel input image is flattened into round input ports that feed two hidden layers of ReLU neurons through weighted connections; four output logits pass through a softmax block into a pixel bar chart of class probabilities, where the second class wins at 0.81. One highlighted signal path runs from an input row to the winning bar, and a forward pass travels along it layer by layer. 8×8 PXINPUT HIDDEN RELUWEIGHTS SOFTMAX 0.060.810.100.03OUTPUT
Feed-forward neural network: pixel input, two ReLU hidden layers, softmax output over class probabilities.
Power-to-X superstructure: candidate technologies and the selected designOrthographic superstructure for a hydrogen-based water-energy-food system. Resources (solar, wind, seawater) feed candidate technologies (battery, PEM electrolyzer, reverse-osmosis desalination, hydrogen storage tank, Haber-Bosch ammonia synthesis, methanation) that supply products (power, hydrogen, ammonia, methane, water). Each technology carries a binary build decision y in {0,1}. The drawn selection (solid, y=1) is electrolyzer, desalination, storage and Haber-Bosch; battery and methanation stay candidates (dashed, y=0). Nitrogen and carbon dioxide enter as battery-limit feeds. Every selected unit has its inputs supplied and its outputs consumed.H₂OH₂N₂CO₂011110POWERH₂NH₃CH₄WATERRESOURCESTECHNOLOGIESPRODUCTSELECTROLYZERSTORAGEHABER–BOSCHMETHANATIONDESALINATION10SELECTED (y=1)CANDIDATE (y=0)
Superstructure optimization for a Power-to-X system: every candidate technology and link, with the selected design (y = 1) drawn solid.
Two-piece floating ball valve Isometric drawing of a two-piece floating ball valve, NPS 2 (DN50) class 150, flanged, 178 mm face to face, shown open: lever and ball bore parallel to the pipe. Open view: the front half of end cap, body, ball, seats and packing is cut away on the plane of the pipe and stem axes. One 49 mm bore runs straight through end cap, PTFE seats and ball (full bore), with the flow centreline. A tang on the stem engages a slot across the ball crown, parallel to the bore, so the ball floats against the downstream seat. Three packing rings and a gland follower fill the stuffing box in the neck. Six studs clamp end cap to body; two lie in the cut plane. Gland nut, lever and lever nut are exploded up the stem axis on a dashed guide; the lever has a bent stop tab. Closed view: the assembled valve, lever seated, its tab against a stop pin on the neck collar. END CAPPACKINGSTEMBALLPTFE SEATBODY GLAND NUT LEVER
Floating ball valve, DN50 class 150, half-sectioned; a quarter turn of the ball shuts the line.
Jacketed continuous stirred-tank reactor Exploded isometric cutaway of a jacketed stirred tank. A finned electric motor, gearbox and coupling drive a shaft and four-blade impeller. Two wall baffles interrupt swirl. A sparse dither band shades the liquid; hatched sections distinguish the pressure wall from the cooling jacket. A flanged feed enters the raised lid, two side nozzles serve the jacket, and a separate lower nozzle withdraws product. Closed, the lid and drive seat on the vessel flange and the intact jacket covers the cut. FEEDDRIVEBAFFLEIMPELLERCOOLINGPRODUCTJACKET
Jacketed continuous stirred-tank reactor, cut away: feed, impeller, baffles, cooling jacket, product outlet.
Pareto front: cost against CO₂, solved by ε-constraint Bi-objective design trade-off, both objectives minimised: total annualised cost c in M€/a (horizontal) against CO₂ emissions e in kt/a (vertical). The attainable set is bounded by the convex frontier e = -4 + 434/(c − 8.5) for c from 12 to 24. 11 efficient designs lie on it, evenly spaced along the drawn curve; 210 seeded candidate designs (small dots) lie above it inside the ideal–nadir box. A non-dominated filter over all 221 designs returns exactly the 11 efficient designs (round markers on the 2-unit Pareto front); every small dot is dominated by at least one of them. Axis ticks: cost 12 to 24 M€/a in steps of 3, CO₂ at 50, 75, 100 and 120 kt/a. Utopia point (12, 24) and nadir point (24, 120) span the dashed box. Dashed ε-lines show the ε-constraint method, min c subject to e ≤ ε, at ε = 89.27, 62.42, 43.18, 31.35 kt/a; each touches the front at its optimum, c = 13.15, 15.03, 17.7, 20.78 M€/a, where the constraint is active. The hatched quadrant is the region dominated by design A (15.03, 62.42). Inset: design A against design B (20.78, 31.35) as pixel bars, cost and CO₂, each metric on its own zero-based scale. 12151821245075100120COST M€/aCO₂ kt/a ABABAB COSTM€/aCO₂kt/a15.020.86231 PARETO FRONT ε-CONSTRAINT UTOPIA NADIR DOMINATED
Cost versus emissions: candidate designs, the Pareto front, and solutions found with the ε-constraint method.
Model predictive control: the receding horizon Two stacked time plots split by a vertical line at the current sample k. Upper plot: the measured output y of the first-order plant y[t+1] = 0.8 y[t] + 0.2 u[t], steady at 0.2 until the set-point steps to 1 at k-3, then rising; to the right of k, the dashed reference r = 1 and the predicted output y-hat(k+i|k) over a prediction horizon of Np = 10 samples, which is the model rolled out on the planned inputs. Lower plot: past inputs as zero-order-hold bars, then the plan from the quadratic cost sum (y-hat - r)^2 + 8 sum du^2 with control horizon Nc = 4: four shrinking upward moves, held constant afterwards. Only the first move, u(k), is applied; at the next sample the window shifts one step and the problem is solved again. y u t PASTPREDICTION HORIZON NCONTROL HORIZON NNOW (k)REFERENCE rPREDICTED ŷAPPLIED u(k)
Model predictive control: the prediction and control horizons at time k, the predicted output, and the first planned move that is applied.
MILP: a relaxation, an integer cut, and a proof Integer program: maximize cᵀx = 4x₁ + 3x₂ over integer x₁, x₂ subject to x₁ ≥ 1, x₂ ≥ 1, x₁ + x₂ ≥ 4, 3x₁ + x₂ ≤ 19, x₁ + 3x₂ ≤ 19 and x₁ ≤ 5.5. The hatched hexagon is the LP relaxation, with vertices (1, 3), (1, 6), (4.75, 4.75), (5.5, 2.5), (5.5, 1) and (3, 1); its hollow optimum is the vertex (4.75, 4.75) with bound 33.25. Solid dots are the 22 feasible integer points, faint dots are infeasible ones; the ringed integer optimum is (5, 4) with value 32. The dashed Chvátal–Gomory cut x₁ + x₂ ≤ 9, the sum of the two ≤ 19 rows divided by 4 and rounded down, passes through (4, 5) and (5, 4), keeps every feasible integer point and removes the dithered wedge that holds the LP optimum. The faint dashed iso-objective line cᵀx = 33.25 touches the relaxation only at the LP optimum; the objective arrow c = (4, 3) stands perpendicular to it and points toward increasing cᵀx. Branch and bound on x₁ = 4.75: the child x₁ ≤ 4 has LP optimum (4, 5) with value 31, the child x₁ ≥ 5 has LP optimum (5, 4) with value 32; both are integral, so 32 is optimal and the gap to 33.25 is closed. x₁ x₂ cTx CUTx₁+x₂≤9 FEASIBLEREGION LP OPTIMUM INTEGEROPTIMUM BRANCH &BOUND 33.25 x₁ ≤ 4 x₁ ≥ 5 31 (4,5) 32 (5,4)
Mixed-integer program: integer lattice, LP relaxation, a valid cut and the branch-and-bound tree.
Two-stage stochastic program: scenario tree with recourse Two-stage stochastic program min cᵀx + Σ p_s Q(x, ξ_s), drawn as a scenario tree. The first-stage decision x (installed capacity: PV 2.5 MW, wind 1.5 MW, battery 2 MWh, shown as pixel bars in a double-rimmed node) is a single node shared by every scenario, which is non-anticipativity. It fans out to four renewable-availability scenarios with probabilities sunny 0.35, windy 0.30, cloudy 0.25, calm 0.10 (sum 1.00). Each scenario card is a 24-hour sparkline of available renewable output (PV plus wind, MW) in 0.4 MW pixel steps, with the flat 1 MW load as a dotted line. The recourse y_s is the hourly dispatch: surplus charges the battery (90% efficient), deficits discharge it, and the rest is imported at 100 EUR/MWh. Q(x, ξ_s) is that import cost in thousand EUR per day (0.82, 0.23, 0.65, 1.73), and the probability-weighted bracket gives E[Q(x, ξ)] = 0.69. FIRST STAGE xPV2.5 MWWIND1.5 MWBATT2.0 MWh 0.350.300.250.10Σ 1.00ps SUNNYWINDYCLOUDYCALMLOAD 1.0 MWSCENARIOS ξs 0.820.230.651.73RECOURSE ysQ(x,ξs) E[Q(x,ξ)]= 0.69 k€minxcTx+Σs ps Q(x,ξs)
Two-stage stochastic program: one first-stage design x, scenarios ξₛ with probabilities pₛ, recourse yₛ, and the expected recourse cost.
Compass: the construction of the KA monogram Construction board of the KA monogram. The K's leg is a circular arc centred on the A's apex; it runs on through the A as its crossbar. The apex and the K's joint are the ends of a 3-4-5 right triangle, four strokes across along the cap line and three down the stem's axis, so the hypotenuse, five strokes, is the compass radius of the arc's centreline; the arc's inner and outer circles are 26 units apart. The arm leaves the joint along a 3:4 line, the mirror of the arc's start. Dotted axes, dashed cap line, baseline and centreline, solid primary construction and hollow anchor nodes at the apex, the joint, the cap-line corner, the arm's top, the A's inner apex, the crossbar on the axis and the outer corners.
Construction of the KA monogram: the K's leg is an arc centred on the A's apex that runs on as the crossbar; apex and joint close a 3-4-5 triangle whose hypotenuse is the compass radius.
